Chapter 9

Instrumentation for UFO Searches

Frederick Ayer II


1. Introduction
2. The All-Sky Camera
3. The Prairie Network
4. Evaluation of the Prairie Network
5. The Tombaugh Survey
6. Scanning Photometers
7. Haleakala I
  8. Haleakala II
9. Radar
10. The Image Orthicon
11. Proton Magnetometers
12. Lasers
13. Observations and Comments
14. Recommendations

BACK to Contents

NCAS Editors' Note: The figure numbering in this chapter was incorrect. We have re-numbered the figures where necessary, based on the text that references each figure. Where these changes were made, the original numbers also appear in square brackets. Some figures had no captions; we have provided them based on the descriptive text. Some figures are out of order (mispaginated) in relation to the text; these have been left in place as the renumbering establishes the proper relationship of text to figure.

1. Introduction

Most of the thousands of existing reports of UFO phenomena are poor sources of information. They contain little or no data, are reports of hoaxes, or are the result of misidentification of familiar objects. Only a very small percentage of these reports provide concrete information from which any inferences can be drawn.

The need for instrumented observation of UFO phenomena arises from the fact that an observer's unaided senses are not reliable recorders of scientific data. Further, the ability of an observer to supply useful information is affected by his training, his state of mind at the time of the observation, and his suggestibility, both during and after the event. Accuracy requires instruments to measure precisely data such as angles, apparent or real velocities, distance, color, and luminance.

Even an observer with optimal training, objective state of mind, and minimal suggestibility is hard pressed when unassisted by instruments, to provide useful scientific information. This is especially true in the case of UFO phenomena, which are typically of short duration, occur in an unfamiliar environment, and lack points of reference from which reasonable inferences as to distance, size, and velocity can be drawn.

Even when instruments are available to him, the observer and the analyst of his report must be aware of a process inherent in any scientific inquiry; namely, the tendency of the investigator to look for evidence to support or discount a given hypothesis. In this state of mind, the investigator tends to disregard all data from his instruments that are irrelevant to his predetermined goal. An air traffic controller, for example, concentrates on radar echoes that he feels

[[1214]]


quite certain are those that come from those aircraft for which he is responsible. A meteorologist focuses his attention on quite different data on the radar scope: thunderstorm, tornado, and frontal activity. The military observer pays less heed to natural phenomena and concentrates on data on the scope that might signify the approach of ballistic or orbiting bodies.

In other words, almost all investigative processes begin with a built-in "filter" designed to minimize whatever, for the investigator concerned, constitutes "noise." But one man's noise is frequently another man's data. The physicist interested in the elastic scattering cross-section of pi-mesons interacting with protons begins his analysis by setting up criteria that tend to eliminate all inelastic events.

This filtering process turned out to be at work when researchers in atmospheric physics examined the read-out of a scanning photometer, an instrument normally used in studies of airglow. The device scans a sector of the sky and records the result as a trace on paper tape. The zodiacal light and the Milky Way appear as broad humps; stars and planets as sharp spikes. An UFO would also appear as such a spike, but its motion would cause the spike to appear in different parts of the sky in successive scans.

Would the operator of the scanner notice such a trace? Or would he ignore it, along with the star and planet "noise"? Since his attention is focussed on the traces that indicate airglow, it seemed likely that he would fail to notice any trace attributable to an UFO.

This proved to be the case. Examination by project investigators of a zodiacal light photometer read-out made at the time of a visual sighting revealed four spikes in successive scans that could not be attributed to stars or planets. The personnel analyzing the data had ignored them. Geometric reconstruction of the object's path established that the photometer had recorded a ballistic missile in trajectory over the Pacific Ocean. Details are found in Section 8 of this chapter, "Haleakala II."

But even if the operator of an instrument fails to notice what, to him, is noise, another operator employing the same device for a

[[1215]]


different purpose has access to all the recorded data md can therefore search for the specific information of interest to him. As demonstrated in the case of the scanning photometer, the instrument can be employed to provide a record of an UFO that can later be subjected to scientific analysis. Not all existing instruments, however, have adequate resolving power or other design features for effective searches for UFO phenomena.

Future studies of UFO phenomena should, in my judgment, be based upon information recorded by suitable instruments. This chapter will discuss existing instruments and instrument systems with special reference to their suitability for an UFO search. It will also suggest what instruments and instrument systems might be devised that would more readily yield suitable data for the study of UFO phenomena.

BACK TO TOP

2. The All-Sky Camera

The all-sky camera was developed in order that permanent photographic records of the time of occurrence, intensity and location of auroral and airglow displays could be made automatically. During the International Geophysical Year, (1957-1958) 114 all-sky cameras were in operation at sites from near the North Pole to the South Pole.

The cameras are designed to photograph about 160° of the sky and to record angular distances from the zenith by means of lights. Photosensitive detectors switch the cameras on at dark and off at daylight. Exposures are short and can be set to any desired value. Local or Universal Time and length of exposure are recorded on each frame. Table I lists the salient points of the cameras of several participating countries. For further details see: Annals (1962) Gartlein (1947).

The film is examined by trained personnel and the data on auroral position and brightness in each of three areas, as a function of time, are entered on a five-line format called an "ascaplot." The three areas are the northern, zenith and southern. The northern and southern zones cover the regions lying between 600 and 800 from the zenith, and the zenith area takes in the whole of the sky between 600 and the zenith.

[[1216]]


Table 1

Features of Some I.G.Y. All-Sky Cameras


COUNTRY Film width
mm.
Number of exposures per hour Exposure in seconds Film Type Time Accuracy

U.S.A. 16 60-80 alternating 10-20, 15,48 Eastman Kodak Tri-x, Ilford HP-3 ±10 sec. to ±2 minutes
Canada 35 60 4-40 alternating Eastman Kodak Tri-x Pan. ±3 sec. to ±1 minute
Canada 16 60 30 Eastman Kodak Tri-x Neg. ± 1 minute
U.S.S.R. 35 12,60,120, 180 alternating 5,10,20 alternating High sensitivity Negative Pan. ± 2.5 sec.
Japan 16 240 13 High sensitivity Pan. ± 0.3 minutes
Argentina 16 60,48 20 Eastman Kodak Tri-x ± 1 minute

[[1217]]


At a height of 100 km.; the lowest altitude at which auroras generally exist, the camera covers a region of about 30 of latitude.

Most of the cameras record on 16 mm. film, and the diameter of the circular sky image is about 10 mm. Since the individual silver grains in the emulsion are of the order of 1µ (0.001 mm.) in diameter, an image less than 20µ is very poorly resolved. To produce a 20µ image, an object 100 km. distant would have to be no less than 600 meters in diameter. It is apparent that the resolution of such an instrument is not adequate for objects of more terrestrially common dimensions.

The sensitivity of the all-sky camera is also disappointingly low for purposes of UFO search. For instance, referring to point sources, Dr. Gerald M. Rothberg, in his report on one month's observation with one of these cameras, states that five miles is "roughly the maximum distance at which we can detect the landing lights on commercial airliners, as determined from photographs of planes ..."

The sky-coverage of these instruments is very good, however, amounting to about 83% of a hemisphere of the same radius. However, each camera can sample only about 0.2% of the volume of sky 100 km. high over the continental United States, which amounts to about 9x108 km3.

A thorough test of a 16 mm, U.S. all-sky camera was made by Dr. Rothberg during August 1967. (Case 27) The camera was operated for about 150 hours on seventeen nights. Exposures started at dusk and ended at dawn. The camera made one 40-sec. exposure per minute. The total number of frames taken was about 9,000 during a period when 106 local UFO sightings were reported. Rothberg states that

... continued at high frequency during the feasibility study, less than 12 of 9,00U all-sky camera exposures contained images not immediately identifiable. Only two of these coincided in time and azimuth with a sighting report. Study of one negative suggests that the image is either that of a meteor whose path was at or nearly at a right angle to the focal plane or that an emulsion defect or impurity is responsible for the image. The other negative's image was identified as a probable aircraft. (Case 27).

[[1218]]


One UFO sighting was definitely recorded by the camera; the objects were three garment-bag balloons which were photographed repeatedly over a period of 15 min.

In appraising the value of the all-sky camera as the instrument to use in any follow-up investigations, Dr. Rothberg is "less than enthusiastic about (their) use" for an UFO search.

Put very simply, a camera designed for the observation of airglow and auroral phenomena, both of which are large, amorphous luminous regions, does not have the resolution necessary for investigating phenomena such as fireballs, ball lightning, tornadoes, or UFOs.

BACK TO TOP

3. The Prairie Network

Instrumented meteor astronomy is a comparatively young field dating back not much before 1936 when the Harvard Meteor Project began. Determination of mass distributions, size and composition has been difficult because results have to be arrived at by inference only instead of from studies of samples collected in the field.

Current theory holds that meteors originate from two sources: comets and asteroids. It is thought that meteors which survive long enough in our atmosphere to reach the surface are asteroidal in origin. From spectroscopic evidence it appears as if comets were composed of solid particles - "dust" - weakly bound by material which can exist in solid form only at very low temperatures. Only the dust can exist for an appreciable time in the solar system, and it is these solids which appear as cometary meteoroids. As a matter of interest, this does not preclude the deep penetration of our atmosphere by large cometary fragments. The Tunguska Meteor of 1908 is thought to have been such a fragment, and the devastating effect of this encounter is still visible today (Krinov, 1963).

Almost all meteorites in museum collections were found accidentally and the time of landing for about half of them is unknown. Seeking to increase the recovery rate and to pinpoint the time of arrival, the Smithsonian Institution began to design the Prairie Network in

[[1219]]


the early 1960s (McCrosky, 1965) in such a way as to increase the area coverage over that of the Harvard Project and to improve the probability of observing large, bright objects. Between 1936 and 1963 four technical advances proved particularly important in the basic design of the system: the Super-Schmidt camera, much faster photographic emulsions, radar, and the image orthicon. The Super-Schmidt and high-speed film were originally used in an effort to determine the trajectories of faint meteors having initial masses of ~102 gm. The radar and image orthicon have been combined into a system for the study of meteors which are fainter than the Super-Schmidts were capable of detecting, and which are presumed to be of cometary origin. A grant from NASA established the network and the first prototype photographic station went into operation at Havana, Ill. in March 1963. About a year later, the network first functioned when ten stations began working reliably.

The complete network now consists of 16 stations of four cameras each, located at the apices of a set of nesting equilateral triangles having a separation of 225 km. Each of the four cameras is aligned with a cardinal point of the compass with the diagonal of its 9.5 sq. in. film oriented vertically. The optical axis of the camera is elevated at an angle of 35° to the horizon, but as the effective field of the present lenses is ~100° one corner of the film will photograph ~1O° below the horizon and the extreme of the opposite corner falls short of covering the zenith by ~10° (See Fig. 1) As a result, there are five blind spots, one vertical and the other four at true compass bearings of 45° 135°, 225° and 315°, amounting to about 20% of the total hemisphere. All 16 interlocking stations cover a total impact area of 1,500,000 km2.

The Super-Schmidts are capable of recording stars with a photographic magnitude of as low as Mpg = +3, but the network cameras have considerably lower sensitivity, computed at Mpg = -3.

The angular velocity of the meteorite is determined by interrupting the streak of its path on the film by means of a shutter that

[[1220]]


Fig 1

Figure 1: Prairie Network

Click on thumbnail to see full-size image.

[[1221]]


runs continuously. The shutter motion is interrupted at regular intervals in order to produce a timing code that indicates time in reference to a clock face photographed on each frame. This permits fixing the time of passage with respect to the exposure interval.

The standard exposure is three hours so that three to four frames are produced each night. Operation of the camera is controlled by photosensitive switches that turn the system on at twilight and off at dawn. To prevent fogging by moonlight or other bright sky conditions, each camera is equipped with both a neutral density filter and a diaphragm activated by a photometer.

Other features insure the proper exposure and recording of time intervals of meteors having a photographic magnitude greater than Mpg = -6.

Stellar magnitudes are stated on a logarithmic scale. A difference of five magnitudes corresponds to a ratio of brightness of 100. Because the astronomers traditionally have referred to a bright star as being of "the first magnitude," and less bright stars as being "second magnitude" or "third magnitude" stars, the sign given to a magnitude is inverse to its brightness. An object of MV -1 is, by this convention, 100 times brighter than an object of MV +4 (a difference of five magnitudes). Magnitudes of some familiar heavenly bodies are: sun -26.72; full moon ~-12; Venus -3.2 to -4.3; Vega +0.1; Polaris +2.1. The faintest magnitude visible to the normal, unaided human eye is about +6.

Photographic (Mpg) and radar (Mrad) magnitudes are related to visual magnitudes by coefficients which are functions of the wavelength of the radiation as well as the characteristics of the detector.

Although a meteor may be recorded by more than two cameras or stations, only two views are necessary to determine altitude, velocity, and azimuth. The two best views are those in which the line joining them is the most nearly perpendicular to the trajectory. Such stereo pairs will detect meteors at altitudes of 40-120 km. If the measurements indicate that the meteor may land in a region relatively

[[1222]]


accessible to network personnel, a third view of the trajectory, downstream from the first pair, and where the meteor has fallen to an altitude of between 10 and 40 km., is then measured to determine the rate of momentum loss from which the impact ellipse is computed.

Exposed film from one-half of the stations is collected every two weeks and scanned at field headquarters in Lincoln., Neb. The rate of acquisition of film is ~500 multi-station and ~500 single-station meteors per year. Frames with meteors from one station are cut out of the film strip and a search is made for views of the same event taken at other stations. The assembled events are then sent to Cambridge, Mass. for measurement. It is necessary to measure the length of every interval on the meteor track produced by the shutter, the positions of about forty stars, and to make densitometric measurements of the trace.

One of the most important functions of the network is to facilitate recovery of meteoritic material. The network's design is adequate to provide an "impact error" of 100 meters for the "best determined objects." But such accuracy fails to guarantee recovery because the object of search is nearly indistinguishable from the more common field stones. One recent search occupying 150 man-days resulted in no recovery. Since the start of the project some 500 man-days of search have yielded no recoveries.

In contrast, the Canadian "network," which was not yet in operation by June 1968, has already recovered at least one meteor by careful and extensive interrogations of persons who had witnessed meteor falls. Similarly, in Czechoslovakia, four pieces, out of the many which make up the Pribram meteor, were recovered before the impact point had been determined from data obtained by a simple two-station system not designed for this purpose.

[[1223]]


BACK TO TOP

4. Evaluation of the Prairie Network

Colorado project scientists attempted to evaluate the usefulness of the Prairie Network as an instrumented system for UFO searches. A list of UFO sightings dating back to 1965 that occurred within the network limits was presented to the supervisor of the field headquarters in Lincoln, Neb. He was requested to produce those plates which might conceivably have been able to photograph the objects which gave rise to the sightings. Information supplied to the supervisor was deliberately limited to case number, year, month, day, time, city, duration, direction, and location. Duration of the sighting was given in minutes. Direction in the sighting reports referred either to the direction in which the observer was looking, or the direction of motion of the object. Location was specified by the coordinates of an atlas. Presenting the information in this form avoided biases based on preconceptions and placed more emphasis on the immediate environs of the sighting point. The assumption that an UFO was in the immediate neighborhood of the sighting was made so as to combat any tendency to attribute sightings to distant objects, that is, to astronomical bodies.

A map was prepared for each case (see Fig. 2) and each film scanned for exceptionally bright objects and planes or satellites. Tracks of bright meteors were never seen because the films on which they appeared had been sent to Cambridge, but the azimuth, elevation, and trajectory of these meteors were available and correlated with the sighting report. Angular positions of bright objects were roughly determined by means of a template.

[[1224]]


Fig 2

Figure 2: Prairie Network Case Map

Click on thumbnail to see full-size image.

[[1225]]


The following criteria-were applied to the reports and to the films:

Not operating (NO): cameras do not operate before dusk or after dawn and they sometimes malfunction or run out of film.

Meteor (M): a fireball with a known trajectory computed by its film tracks at several stations.

Overcast (O): this applied to cases where two nearby stations were so overcast that no star images showed, and where there was little information on films from more distant stations.

No information (NI): this classification was used when the report failed to state the direction in which the observer was looking or the direction in which the object was moving, or both.

No conclusion (NC): the report information was so fragmentary that no correlation between the objects on the photograph and those reported, was possible, or the films gave no information which could confirm that an object was seen.

Inconclusive identification (II): if the photographic evidence showed the presence of a body which could have been responsible for the sighting with a fair degree of probability, the case was called inconclusively identified.

Conclusive identification (CI): when description in the visual report was confirmed with a high degree of probability in all characteristics, the case was considered to be conclusively identified.

The following rules were adopted:

  1. All NI cases became NC

  2. No NO cases were labelled NC

  3. Some O cases were classified NC

[[1226]]


Of 114 cases, two were identified as meteors, one conclusively and one inconclusively, four cases received conclusive and 14 inconclusive identifications. Of the remaining cases 80 were classified NC; and 14, NI or NI combined with NO and O.

The sighting identified conclusively as a meteor was made by a couple who were driving north on Highway 281, six miles north of Great Bend, Kans., at 2200 CST. They reported that they saw "... a flash or burst of fireworks above car, not unlike the usual Fourth of July fireworks, except that this was much larger and much higher. The fireworks or sparkles were varicolored and out of them emerged a disc-like object about the size of an ordinary wash tub. The object was as red as fire, but it appeared solid with a very definite, sharp edge ... and traveling at a tremendous speed. Its direction was north-northeast and in a straight line ... It did not require more than five seconds to reach a distance that made it invisible ..."

Two phrases in this statement needed clarification: "above us" and "its direction was north-northeast." The observer explained that "above us" meant "through the upper part of the windshield." He said that his (and his wife's) attention was called to the object by the flash of the burst, which they saw just to the west of north, and it vanished while still slightly west of north. He insisted that the object was traveling north-northwest, explaining the correction by saying that he often confused west with east. He was therefore certain that it could not have been on the NW to SE course determined from the photographic data, and that it was not a meteor because it was rising, not falling. Questioned as to the time, he said that 10:00 P.M. was approximate and that the duration of the sighting was short, probably less than the five seconds referred to.

Six stations of the Prairie Network photographed a meteor at about 10:10 P.M., determined that it passed over Republican City, Neb. at an altitude of some 50 km., and predicted that its point of impact was near Downs, Kans. Republican City lies a few degrees west of north from the sighting point at a distance of about 177 km., and Downs

[[1227]]


an equal number of degrees east of north at a distance of about 116 km. Assuming a mean distance of 145 km., the observer saw the meteor at an elevation of approximately 19°. The elevation of the top of a windshield of an American two-door sedan from the eye level of a man of average height is about 25° or less.

The observer's impression was that the object was rising. This would be expected if it were approaching him at a constant altitude. His strong feeling that it was on a northerly course, and therefore receding, is explained by recalling the very short time during which he saw it.

Considering the general agreement as to time, elevation and region of viewing, the probability is high that the object seen was the meteor photographed.

The second case was labeled inconclusive because, in spite of the paucity of information available about it, there was a relatively close agreement between the time of the sighting (0001 CST, 26 January 1967) and the time of a meteor recorded on three network stations (2341:51 CST, 25 January 1967). The discrepancy of only 18 minutes leads to a probable identification of the sighting as the meteor, but the identification cannot be made conclusive.

A striking example of the lack of correlation that can occur between a familiar object and the interpretation of a sighting is related in the case where a large, helmet-shaped, luminous body appeared overhead from behind a cliff. The observer was driving west. He reported that the object stayed nearly overhead for 45 min. until it disappeared behind a hill to the southwest at an altitude of about 40°.

Network photographs show the moon moving from 245° to 270° at a starting elevation of 85° dropping to 45° Stars and a plane also appeared on the film, but their positions did not tally with the report.

Neither the observer nor the Air Force interviewer mentioned that the moon was visible, but the conclusion appears to be inescapable that the object seen was the moon. A summary of the results of this study are presented in Table 2.

[[1228]]


Bearing in mind that Prairie Network optics and geometry were designed to detect bright astronomical objects at high angular velocities, it is not surprising that 100% of the conclusive and 67% of the inconclusive identifications relate to astronomical objects. In fact, any future investigation utilizing the network should guard against a possible bias arising from its design features.

The network's identification of 18% of all sightings with a fair degree of probability, does not constitute as poor a performance as might be thought since 34% could not be recorded because of overcast and 43% were so deficient in information that, even if an object had been recorded by the film it would have been impossible to correlate it with the sighting.

BACK TO TOP

5. The Tombaugh Survey

In 1923, Dr. W.H. Pickering called attention to the possibility that undiscovered small natural earth satellites might exist. In 1952, after a long period of searching for trans-neptunic planets and "lost" asteroids, during which the planet Pluto was found, Dr. Clyde W. Tombaugh began a search for small satellites which might be in circular geocentric orbits having radii between 5,000 and 26,000 mi.

In searching for small, high-velocity bodies having a luminance close to the photographic threshold, it is essential to avoid "trailing"; that is, the image must be kept stationary with respect to the film. For example, if a star image 0.04 mm. in diameter trails over the emulsion for a distance of 10 mm., its brightness at any point will be diminished in the ratio 0.04/10.0 = 1/250 times. The resulting trail image may be below the film's threshold. Therefore, Dr. Tombaugh's experimental method was based on searching the surfaces of a large number of spherical shells, each concentric with the earth. The angular velocity of the search in each shell was made equal to the angular velocity a body moving in the gravitational field of the earth would have at a geocentric distance equal to the radius of that shell. (Tombaugh, 1959).

[[1229]]


Table 2

Prairie Network Study

Summary of Sighting Identifications


STATE O NI NO total NC M CI II conclusively
astronomical
inconclusively
astronomical

S Dak 0 0 0 5 2   0 3   2
Neb. 4 6 0 10 8   1   1
Kans. 3 9 1 14 9 1 0 3   1
Mo. 10 7 2 27 17 1 3 3 3 2
Iowa 3 2 1 11 8   0 2
Ill. 11 16 5 33 27   0 1   1
Okla 3 3 3 14 9   0 2   2

Total 34 43 12 114 80 2 4 14 4 8

% Total 30 38 11   70 2 4 12 100 67

[[1230]]


The minimizing of trailing permitted the recording of images down to the Mpg = +15 in a 2 min. exposure. A dark rock, four feet in diameter, having a reflectivity equal to that of the moon, at a geocentric distance of 26,200 miles, would produce an image of this photographic magnitude.

The project was terminated at the end of June 1956. The number of concentric shells searched was over 100, resulting in a collection of 13,450 photographs. A few dozen possible natural satellite images having photographic magnitudes lying between +16 and +14 were found and attempts were made to recapture them by repeatedly photographing the shells in which they occurred, but with no success. The conclusion is that these images were either film defects, very small asteroids in elliptical orbits around the sun, or natural satellites in elliptical, rather than circular, orbits around the earth.

As a by-product of this project, a search for moon satellites was made during the lunar eclipse of November 1956. Three telescopes, monitored by a sky photometer, produced a total of 25 plates, recording point images down to about Mpg = +17. Some 500 candidates were found in the region between the moon's surface and a lunicentric distance of 37,000 miles, but none survived a detailed analysis.

A program of visual observation for nearby objects at very low latitudes began at the end of 1955 and continued through 1958. The equatorial plane, at distances between 600 and 2,500 miles from the surface of the earth, was searched with a twelve inch Newtonian reflecting telescope and 10 X 80 binoculars. The telescope had a limiting visual magnitude of +11 at 100 miles and +13 at 2,400 miles, while the binoculars could detect objects of MV = +8 at 100 miles and of MV = +9 at 2,800 miles. No satellites were seen. In the words of the report:

It is most unlikely that any objects larger than two feet in diameter at an altitude of 100 miles or twenty feet at 2,500 miles as seen by binoculars, and several inches at 100 miles or three feet at 2,500 miles as seen

[[1231]]


by the telescope existed ... during 1956, or that any natural objects have since entered these regions.

The method used by Dr. Tombaugh, while admirably suited to orbiting bodies, is not appropriate for the observation of aerial phenomena that are not constrained in circular orbits. If their distances from the cameras were large they would not be detected due to the effect of trailing. For this reason a search on satellite survey films for reported UFOs was not attempted.

BACK TO TOP

6. Scanning Photometers

Photometry of the night sky is carried out by means of photomultipliers which sweep out circles parallel to the horizon (almucantars) at various zenith angles Z (Z = 90 ° - altitude). Photometers used in airglow studies have a 5° field and sweep at the rate of 10°/sec horizontally and 5°/sec vertically. A "sky survey" consists in making 360° sweeps at each of six zenith angles as follows: scanning clockwise at Z = 80° at the rate of 10°/sec, counter-clockwise at Z = 75° at 5°/sec and repeating the process at the same rate at Z = 7° 60°, 40°, and 0°. A survey requires 4.1 min. Often a series of surveys is made using different filters depending on the nature of the investigation.

The output of the instrument consists of pulses, the amplitude of which is proportional to the intensity of the light sensed by the photometer. In older models the output is recorded analogically by a pen on paper tape. Since the distance along the length ("x" axis) of the tape is proportional to the time of the scan, it is therefore an indicator of the azimuth and zenith angle of the light source represented by the pulse. Data are analyzed by measuring the height of pulses of interest ("y" axis) and determining their azimuth at each zenith angle. This measurement is done manually or in the new model, by recording the coordinates directly on machine-readable magnetic tape.

[[1232]]


The angular size of the field, sweep rate, and other quantities differ depending on the use to which the instrument will be put. A zodiacal light photometer, for example, has a narrower field, 3°, scans at about 2°/sec and sweeps out almucantars at much smaller zenith distances, that is at altitudes much closer to the zenith.

Bodies brighter than MV = +3 can readily be identified by their angular coordinates coupled with pulse height which is a measure of their magnitude. In practice, however, identification is rarely carried out because investigators of airglow and zodiacal light are interested in diffuse light phenomena rather than in single bright objects.

The sky coverage of the photometers is large since they can be made to scan an entire hemisphere as in the case of the all-sky cameras. The fact that they do not do so in the same short period of time as the cameras is not very important since at large distances the linear sweep speed approaches the velocity of light. Because their observations are made over a longer period of time and their angular data is recorded over a very much larger area, they have a greater resolution; azimuth and altitude are presented more accurately and the direction of motion is non-ambiguous.

Colorado project scientists thoroughly searched two such photometer sky surveys. The first search was made on an airglow survey chosen at random and the results are summarized in section 7 of this chapter. The second search was prompted by a visual sighting by three trained persons of a bright object in retrograde (E to W) motion during the operation of a zodiacal light photometer.

Scanning photometers can also sense different colors on separate surveys. The instrument's ability to measure the degree and direction of polarization can also aid in determining whether the object is self-luminous or its light is reflected. For these reasons, and because of their relatively extensive sky coverage, scanning

[[1233]]


photometers can be considered useful instruments in the conduct of UFO searches.

BACK TO TOP

7. Haleakala I

A search was made of the taped output of an airglow photometer survey recorded around midnight, Hawaiian Standard Time (HST), 11-12 February 1966 in order to see if all bright objects could be identified as stars or planets. This survey was chosen at random from a sample of surveys made under particularly good conditions, that is, on nights during the dark of the moon with the minimum interference from clouds. The taped data, consisting of brightness as a function of azimuth, was plotted by machine in two ways, the first showing the raw data which included light from all sources, and the second, the raw data from which the background of zodiacal light, Milky Way and integrated starlight had been subtracted. On both plots, individual stars and planets stand out as narrow pulses, their height being proportional to their apparent magnitudes. The brightness is measured in terms of the number of 10th visual magnitude stars per square degree of sky, that is, in "S[10](vis)" units.

The observations of that night were made through three filters successively: 6300 ± 5 Å, 5577 ± 5 Å and 5300 ± 25 Å. As each survey through each filter requires about four minutes, successive sweeps at the same zenith distance through the same filter occur at ~15 min. intervals, and one sweep at, say Z = 80°, will be followed by a sweep at Z = 75° about 36 seconds later and repeated at the same altitude about 15.5 min. later.

No stars or planets showed up in the surveys through the 6300 Å and 5577 Å filters, but probably because of its broader band-pass, many more appeared when the 5300 Å filter was used. In this survey, all star pulses greater than MV = +3 were accounted for by reference to a star atlas, except for two. These have been designated as Unidentified Bright Objects (UBO), having the coordinates given (see Figs. 3 and 4) below (see also Figs. 5 and 9 [5 & 6]).

[[1234]]


Fig 3

Figure 3: Haleakala I: Feb 11-12, 1966, 0005h (Hawaii Time)

Click on thumbnail to see full-size image.

Click HERE for editors' note on Haleakala figures.

[[1235]]


Fig 4

Figure 4: Haleakala I: Feb 11-12, 1966, 2350h (Hawaii Time)

Click on thumbnail to see full-size image.

Click HERE for editors' note on Haleakala figures.

[[1236]]



Angle Z HST Azimuth

80° 2350 68°T
75° 0005 72°T

The pulses were separated by 4° in azimuth and 5° in altitude. The azimuthal error in this photometer can be as great as ± 4°. Since the field is 5° and the point source can be sensed equally well over almost the entire width of the field, the altitude uncertainty may be ± 5°

From the recorded values of the angles, if the two pulses were made by one body, it moved an angular distance of

Angular Distance

If the errors are in phase, then, maximally:

Max Angular Dist

and minimally

Min Angular Dist

The fact that the UBO appeared on only two sweeps out of many surveys may be interpreted to mean that it vanished in the shadow of the earth at z = 75°. This situation is shown two-dimensionally in Figs. 5 and 9 [3 & 4].

In Fig. 5, which is a view of the earth, looking toward the southern hemisphere, Haleakala (21°N) lies on the earth-sun line at 2400 HST, and the edge of the earth's shadow is parallel to it. In the first approximation, the distance d from Haleakala to the shadow line in an easterly direction is

d ~ R = 6371 km.

and

OH = d/cos 10° = 6469 km.

The nominal, maximum and minimum distances travelled by the object are:

OBnom = 6469 x 0.1134 = 734 km.

OBmax = 6469 x 0.2240 = 1449 km.

OBmin = 0 km.

[[1237]]


Fig 5

Figure 5: Haleakala I, UBO Data

Click on thumbnail to see full-size image.

[[1238]]


in 15 min., for a velocity of:

Vnom = 48.9 km/mm nom

Vmax = 96.6 km/mm max

Vmin = 0km/mm

These velocities should be compared with those of the UBO in Haleakala II, that is, ~142 mi/min = ~228 km/min. If the UBO was in orbit, the distance GB is the projection of its path SB making an angle Beta with the line of sight. Assuming that the velocity in Haleakala II is typical, then

Angle Beta

and the object was in a highly elliptical orbit. Alternatively, the distance OB might have been the projection of the apogee of the ballistic trajectory of a body launched in a retrograde direction.

Investigation showed that no sub-orbital missiles were launched from Vandenberg AFB or Pt. Mugu until one or more hours after this sighting. The Aerial Phenomena Office at Wright-Patterson AFB suggests that it might have been an artificial satellite on which information is not readily available. The object is thus in the unidentified category.

[[1239]]


Fig 6

Figure 6: Haleakala II, UBO Data

Click on thumbnail to see full-size image.


Fig 7

Figure 7: Haleakala II, UBO Distances

Click on thumbnail to see full-size image.

[[1240]]


BACK TO TOP

8. Haleakala II

On 10-11 September 1967 three observers at the Haleakala Observatory who were operating two scanning photometers saw a bright object move from NE to W at a low elevation. The paper tape outputs of each instrument were examined; the airglow photometer was operating with red filters and did not record anything which stood out against the background, but the zodiacal light photometer detected the object four times through a 5080 ± 30 Å filter. Other prominent astronomical features, such as Eta Canis Majoris, labelled nCMa, were readily identified. The characteristics and operation of this photometer are somewhat different from the one used in airglow measurements. Its field is 3°; its sweep rate is 2°/sec; and almucantar increments are 1°. Because the focus of attention is the brightness of the zodiacal light a few degrees on each side of the plane of the ecliptic, the sweep was restricted to 160° starting from 0°T, each sweep being completed in 80 sec.

The survey in which the UBO appeared began at 0419 HST and ended at 0451 HST, on 11 September. The tape record is reproduced in Fig. 8 [Fig 1] and the data summarized in Table 3.

The object was identified as OP 8038, a sub-orbital missile, which lifted off Vandenberg AFB at 0425 HST. The great circle distance, d, between launch and observation points, is calculated from the rough coordinates:


  Lat. Long.

Vandenberg 34.5°N. 120.7°W.
Haleakala 21.0°N. 156.0°W.

and it is found that

d = 3762 km.

The position of Haleakala with respect to the shadow-line of the earth is shown in Fig. 6 [Fig 5], which is a view of the earth with the southern hemisphere toward the reader. On 11 September the sun rose at 0618.

[[1241]]


Table 3

Photometer Data of UBO Sighting

  HST

SIGHTING h m s Elevation Azimuth(Psi) t (min.) Delta Psi

1st 04 34 25 14° 47° --- ---
2nd 04 35 28 15° 41° 1.05
3rd 04 37 45 16° 36° 2.28
4th 04 38 37 17° 37° 0.87 -1°

At 0439 HST the point of observation, H, was 70° east of its position at midnight. The distance to the point where the body was last seen is HO which, from known quantities is

HO = 638 km,

and that by the time the object vanished, it had travelled a great circle distance

d' ~ 3100 km

in 13 m 37 s for an average velocity over thee earth's surface of

V ~ 228 km/min.

The distance, d, of the body from the observer at each sighting until its disappearance, which is assumed to be coincident with the time of last observation, is shown in Fig. 7 [Fig 6]. From the angular velocity, the angle of approach, Beta, can be approximately computed; the relevant quantities are listed in Table 4, where Omega°, Omegar is the angular displacement in degrees and radians, respectively, Phi is the projected displacement in kilometers and Vav the average velocity between each observing interval, in km/min. The measure of ellipticity is, as before, Sin Beta = V/228, where Beta is the angle between the trajectory and the line of sight.

[[1242]]


Fig 8

Figure 8: Haleakala II, Photometer Data

Click on thumbnail to see full-size image.

Click HERE for editors' note on Haleakala figures.

[[1243]]


The data were obtained directly from the output tape, eliminating almost completely errors due to manual data reduction. Backlash errors in azimuth are negligible. As a field is only 3°, the uncertainty in altitude is smaller than with a larger field, and remains ±1.5°, the error in Phi for the first interval ~5%, for the second ~10% and very high for the third. However, it must be emphasized that the geometrical reconstruction was quite crude and errors introduced by it are probably greater than instrumental errors. Absence of information about the trajectory introduces the most serious uncertainty and the values for d, Phi, Vav and Beta should be regarded skeptically. The errors shown in Table 4 are derived entirely from the uncertainty in the field.

Table 4


Sighting Interval Omega° Omegar d Phi Vav Sin Beta ~Beta

1-2
6.2 +.3
-.2
0.108 +.05
-.03
1595 172 164 0.72 46°
2-3
5.1 +.5
-.1
.089 +.009
-.002
1356 121 53 0.23 13°
3-4
1.4 +1.3
-.4
.023 +.024
-.005
836 19 22 0.10

[[1244]]


Fig 9

Figure 9: Haleakala I, UBO & Earth's shadow

Click on thumbnail to see full-size image.

[[1245]]


Even though the reconstruction is very approximate, the magnitude of Beta indicates a sub-orbital trajectory, because when last seen the body was

h ~ 638 sin 17° +  6382
8 x 6371
 ~ 194 km.

above the surface of the earth, and at this distance it would be expected that Beta = ~17° for an object in orbit.

BACK TO TOP

9. Radar

The use of radar has spread into many diversified fields since its introduction as an aircraft-tracking instrument at the beginning of World War II. One of the first non-military uses it was put to was tracking weather balloons. Not long after, it was discovered that, given the proper wavelength, radar could detect clouds and the position of rain and hail in storms. Since then its use has extended to tracking satellites, investigating the atmospheres of several planets in the solar system, including our own, determining the trajectory of meteors and predicting their points of impact and studying lightning and violent storms (Battan, 1962).

In general, radar provides information for determining the velocity, range, elevation and azimuth of the reflecting objects in its field of view. Indirectly, it will furnish some data on the state of the matter which is backscattering (reflecting) radio energy; other variables such as temperature and index of refraction can sometimes be inferred.

The resolving power of radar, defined as the minimum distance between two objects (or two parts of one object) necessary to make them appear separate, is poor. Details of the shape of the reflecting object and other features can never be determined except in the most general way and only when the object is very much larger than the radar wavelength. Rayleigh's criterion states, essentially, that in order for two objects to appear separate, the wavelength of the electromagnetic radiation that illuminates them must be of the same order of

[[1246]]


magnitude as, or smaller than, the distance between them. This principle, applied to the most common types of radars used in weather surveillance, explains their lack of resolving power because their wavelengths are ten centimeters or greater. In addition, the argument that the resolving power of the all-sky camera is poor because the ratio of image size to emulsion silver grain size is small, applies here: if the range of a typical weather radar is 450 km., the ratio of the area of the image of even large solid objects to the area covered by the scope is exceedingly small.

The range resolving power of radar is also dependent upon pulse duration. The limit of resolution in the direction of propagation is half the linear dimension of the pulse because at intervals less than that the echo formed by the leading edge of the pulse reaching the more distant object overlaps the echo formed by the trailing edge of the pulse returning from the nearer object. Thus, if the radar is "looking" at two objects in its "line of sight," and if its pulse duration is 1 µsecond, it will not display as separate from each other, in-line targets whose ranges differ by less than 500 ft.

Radar reports information in three coordinates: range, elevation, and azimuth. The resolving power in the range coordinate is determined by pulse duration. Resolving power in elevation and azimuth depend upon the same conditions that apply to optical resolution. Rayleigh's criterion for the optical resolution of a telescope can be used for this purpose, if the radar antenna is circular and its diameter is regarded as its aperture. Resolving power is proportional to the ratio of the wavelength to aperture (diameter). This is another way of saying that the ratio determines the angular beam width of a radar transmitting-receiving antenna. Resolving power is determined for this case by the equation

r = 70°(Lambda/D)

where Lambda is wavelength, D is antenna diameter, and 70°(= 1.22 rad.) is the angular size of the diffraction disc image of a point source for unit Lambda/D ratio as derived by Rayleigh. (For other than

[[1247]]


antennas with a circular aperture, resolving power must be separately computed for the vertical and horizontal planes). Applying the equation to a radar with a wavelength of 3 cm., and whose parabolic antenna has a diameter of 3 m., the beam width, and therefore the resolving power, is found to be 0.7° of arc in elevation and azimuth.

Radar is frequently able to see targets virtually undetectable by the unaided eye or on photographic film. This greater sensitivity is due to marked differences in the signal-to-noise ratio of wavelengths employed by radar compared to the optical wavelengths upon which the eye and the camera must rely. The atmosphere is almost completely transparent to radar wavelengths between 3 cm. and 10 cm. It scatters such waves hardly at all. At optical wavelengths, it is still relatively transparent, but air scatters energy appreciably, especially at the short (blue) wavelengths (Rayleigh scattering): hence, the blue sky. In addition, unlike the radar case, there is a powerful source of optical noise present in the daytime sky -- the sun. Thus, a pale blue object seen against the sky is nearly invisible to the retina or to photographic film, yet if constructed of metal, the object will reflect radar waves strongly.

Design of a radar to track targets very much smaller than the wavelength takes into account that for a given wavelength, backscattering power varies as the sixth power of the target size (Rayleigh's Law of Scattering) and, conversely, for a given target size the power varies inversely as the fourth power of the wavelength. Furthermore, atmospheric attenuation of the beam increases as frequency increases. The balancing of these factors results in the choice of a 10-20 cm. wavelength for radar which are to survey extensive storms such as hurricanes; 3-10 cm. for tracking metallic objects; and 1-3 cm. for studies of rain and hail distributions (Battan, 1959).

[[1248]]


The first exact theory of scattering of electromagnetic waves by a sphere was developed by Gustav Mie in 1908. In this theory, the dielectric constant and therefore the index of refraction of the sphere determines in large part the amount of backscatter at any wavelength (Born, 1964). For example, the backscatter from a hailstone is enormously greater than that from a raindrop of equal size, and, as a result, radar can provide data for estimating the amount of ice or hail in a storm cloud. In effect, therefore, it can give information on the state of matter in the scattering object, for example; it can distinguish between wet and dry hailstones.

Anomalous reflections called "angels" can sometimes be ascribed to certain atmospheric conditions. Temperature inversions cause rapid changes in the index of atmospheric refraction at the interfaces of the layers and such changes can give rise to radar echoes exactly as similar conditions account for mirages in the case of visible wavelengths. (See Section III, Chapter 5 and Section VI, Chapter 5.)

As would be expected from Maxwell's equations, radar echoes will be produced by regions of high ionization where there is an appreciable density of free charges. This is the reason why lightning paths are visible to radar. The density of charges in the trail of a meteor is different from that in the immediately surrounding space, and the radar echo arises from this difference in space charge, not by reflection from the nucleus of the meteor itself (Lovell, 1954). Depending upon the magnitude of the radar "cross-section" some "angels" can be ascribed to echoes from birds or even insects. "Cross-section" is better defined as the ratio of the reflected power per unit solid angle to the incident power density; in other words, it is a measure of the effectiveness of the target in reflecting radiation and will have a different value for each wavelength. Inasmuch as birds and insects are usually smaller than radar wavelengths, their actual dimensions cannot be measured, although their radar cross-section can be (Glover, 1966). This quantity, for several species of birds and insects is tabulated below as a function of radar wavelength:

[[1249]]


Table 5


TARGET Wavelength Mean cross-section cm2

Hawkmoth 10.7 1.0
Honeybee 10.7 3.0 x 10-3

Sparrow 10.2 15.0
  71.5 2.5 x 102 (a)
  3.5 1.9

Pigeon 10.2 80.0
  71.5 (a) 11.0

Pigeon 3.5 15.0
  3.5 1.1 head
  100.0 broadside
  1.0 tail

(a) Transmitted beam vertically polarized; received echo also vertically polarized.
(Table taken from Glover (1966) and Conrad (1968).

The extreme sensitivity of radar is well illustrated here: The insect targets were at least 10 km. distant and the birds at ranges between 10 and 20 km. when the measurements were made. Because of the poor resolution of the radars, the cross-section is simply a measurement of relative backscattered power and not the actual spatial extent of the object on the radar scope. In other words, the moth can be distinguished from the sparrow only by determinations of the power received rather than by shape and size; the head of a pigeon cannot be differentiated from the tail.

The radar return does, however, contain information which provides a basis for identifying an unknown point target as a bird ...

[[1250]]


Thus, the radar return from single birds in flight differs ... from other possible point or dot targets, such as aircraft, swarms of insects, several birds together, or small clouds or other meteorological structures (Conrad, 1968).

WEATHER RADAR:

Of the 14 types of radars used by the U.S. Weather Bureau, only the WSR-57 which is equipped with a 35 mm. camera appears to be adaptable to UFO searches. The salient features of this instrument are enumerated below:

WSR-57
Wave Length cm. 10.3 (5 and 2.5 cm. planed but not yet on order)
Pulse Length & Rep. rate 0.5 micro/sec at 658 pulses per sec. or 4.0 micro/sec at 164 pulses per sec.
Peak Power Output K.W. 500
Beam Width
Sweep Characteristics Automatic, manual in altitude or azimuth at 0-24°/sec
Scopes PPI, RHI, R, A
Range 464km.
Altitude -10° to +40°

(Source: U.S. Dept of Commerce)
NCAS Editor's Note: Rows and columns reversed.

These radars are placed around the perimeter of the Weather Network and are interspersed with the eastern stations of the Prairie Network in Minnesota, Iowa, Kansas, Oklahoma, Missouri and Illinois. They are, therefore, well located to furnish corroboration of sightings in any future investigations.

The sky coverage of these radars is obviously less than that of the airglow photometers since they are limited in their choice of elevation and they have only a 2° sweep width.

The photographic program which has been carried over the last few years consists in taking one scope picture of one sweep every 15 min. in times of clear weather and more frequently when storms were developing. These films are available for inspection, but the Colorado project

[[1251]]


made no attempt to search for confirmatory evidence of reported sightings because each photograph covers only 1.7% of each hour of elapsed time.

METEOR RADAR:

The facilities of the Radar Meteor Project of the Smithsonian Institution are located at Long Branch, some seven miles south of Havana, Ill. They consist of a network of eight receivers and one 4 Mw, 40 MHz transmitter, with antennas bearing 113°T. This direction was chosen as the most favorable one for the detection of faint meteor trails.

The main lobe of the radiation pattern from the two transmitting antennas is inclined upward at 45° and has a half-power horizontal width of ~20° and a half-power vertical width of ~11°.

Pulses of 6 µsec. duration are emitted at the rate of about 1300 per second, so that the echo from an object 200 km. distant will return within one pulse cycle. An object in the beam at 200 km. will be about 140 km. above Decatur, Ill. The Havana radar is thus designed to scan approximately the same volume of sky monitored by an image orthicon located at Sidell, (near Urbana) Ill. (see Section 12).

The radar will detect meteors as faint as mrad = +13 for counting purposes, and mrad = +11 and will acquire echoes from 3,000-4,000 meteors/hr.

The system is capable of receiving echoes from objects at almost any distance from the transmitter. In order to limit the information to "suitable" meteors, meteor-recognition logic has recently been installed which filters out extraneous signals such as those from aircraft. These echoes are, however, visible on the monitoring oscilloscopes and are characterized by a persistence greater than that of meteors. Data pertaining to "suitable" echoes is recorded on magnetic tape. Similar, but unfiltered data is simultaneously recorded on film (Smithsonian, 1966).

During 1967, many non-meteoritic echoes were seen on the oscilloscopes and recorded in the Havana log book. Using the film record, the Colorado project sought to determine how many of the UFOs sighted during 1967 in a radius of ~140 km. from Havana, had resulted in an

[[1252]]


echo which had been both filmed and logged. Of nine cases (the same used to test the orthicon), seven had occurred when the station was not operating. The eighth case covered a series of sightings over a period of 10 days during which the station was operating. Unfortunately, only very sketchy observing data were available. The object was seen from Kilbourne, about five miles south of the transmitter, "over the west south-west horizon." Station attendants had been alerted that unusual objects had been seen in the area. The absence of entries in the log book implies that nothing unusual appeared on the scopes. This is not surprising because echoes of objects very close to the station are lost in the display formed by the transmitted pulse, particularly at low altitudes. If the objects had been farther away but bearing ~140°T (WSW) they would not have been located within the main lobe of radiation bearing ~113°T. Objects outside this zone of maximum transmitted power would return echoes too faint to be observed against background "noise."

The ninth object is the one that the image orthicon recorded in a test run on November 7th, 1967 at 2330±3 m. It was subsequently identified as a fireball. No simultaneous radar sighting was made because the radar was not in operation.

BACK TO TOP

10. The Image Orthicon

One of the important problems in meteor physics is the crosscorrelation by simultaneous radar and optical meteor observations of ionization and luminous efficiencies as functions of velocity.

The development of the image orthicon has made such cross-correlation studies feasible. The instrument is a conventional vidicon television camera modified so as to increase its sensitivity. This is achieved by adding an image intensifier ahead of the scanning mechanism in the camera. The result yields a sensitivity equivalent to an ASA rating of 100,000. Such extreme sensitivity permits detection of meteors having a limiting magnitude of about +7. This is well within the equivalent Mrad range detectable by radar, and considerably superior to the capability of any photographic system except the 48 in.

[[1253]]


Schmidt telescope at Mt. Palomar. Tests show that the image orthicon will detect 20-30 meteoroids per hour.

The image orthicon site in Sidell, Ill., about 35 mi. SE of Urbana, was chosen by the Smithsonian Institution with two objectives in mind. Using a lens having a 16° field (the optimum lens for meteor surveys), the image orthicon is sited to survey approximately the same area of sky over Decatur as that covered by the 20° beam of the Long Branch radar (see previous section). But whereas the radar is sited so as to track the meteor trails at about right angles, the image orthicon is located so that its optical axis is more nearly parallel to the meteors' paths.

Linked by microwave and radio, the radar and the image orthicon are able to determine times within 10^-2 sec., thereby minimizing ambiguities as to the identity of the objects observed.

As in conventional television, an 875-line scan samples the tube target in two sets of sweeps of alternate lines, each requiring 1/60 sec. When the alternate sweeps are interlaced, flicker and resolution are greatly improved. The electronic image is recorded on magnetic tape and can be immediately played back for viewing on a monitor. Used in this way, the high sensitivity of the image orthicon permits the acquisition of moving aerial objects that would be undetectable photographically because of the effect of trailing. Photographic records of the monitor images can be recorded by a 35 mm. camera operating at any desired frame speed. The sensitivity of some image orthicons can be further increased by operating them in the integrating mode. In this procedure, the electronic image is swept away less frequently, thereby allowing the photoelectron population due to ultrafaint images to build up. The Smithsonian image orthicon has no provision for this technique, nor does its camera permit the making of time-lapse photographs which are preferable when the device is operating in the integrating mode (Williams, 1968).

During 1967 there were nine sightings of UFOs within a distance of ~200 km. from Urbana. (These were the same sightings which were

[[1254]]


correlated with the radar records.) Eight of the sightings occurred before testing of the image orthicon began in August. The ninth was a sighting on 7 November at 2230±3 min., of a bright object between Urbana, Ill. and Lafayette, Ind. This event was recorded on the image orthicon tape during a test. A film of the tape clearly shows a bright mass moving rapidly across a corner of the field. The object is badly resolved due to its great brightness, but the shape of the image suggests that the meteoroid had already broken into two pieces. Preceding the meteoroid image is a large ghost image which is the result of reflections between the lens elements. Just prior to the appearance of the meteor, a small object can be seen moving at 90° to the fireball trajectory. This object has been identified by Wright-Patterson AFB as a satellite.

BACK TO TOP

11. Proton Magnetometers

The variation in the magnitude and direction of both the horizontal and vertical components of the earth's magnetic field is of such importance in geophysics that a network of some 240 geomagnetic observatories have been deployed by several countries at stations all over the globe (NAS 1968). Thirteen of these stations exist in the continental United States and of these, three are situated on the western edge of the Prairie and Weather Radar networks.

Most of the instruments at the geomagnetic stations are proton magnetometers. These instruments have a sensitivity of about 1 Gamma (=10-5 gauss) in magnetic field strength. This means that the instrument is capable of detecting at a distance of 185 m. the field strength along the axis of a single-turn circular conductor 20 m. in diameter in which a 100 amp. direct current is flowing. In addition to this extreme sensitivity to field-strength fluctuations, the proton magnetometer is capable of detecting 0.1' of arc in declination, defined as the deviation of the horizontal component of the earth's magnetic field from 0°T. Since the mean strength of the earth's magnetic

[[1255]]


field at midlatitudes is about 50,000 Gamma, the instruments are sensitive to about one part in 50,000 of the earth's field.

Assuming a model consisting of a line current in the vortex extending from the ground to a height of 10 km. and an image current of equal length in the earth, Brook (1967) calculates that the current in a tornado, which caused a 15 Gamma deflection in a magnetometer 9.6 km. distant, was about 1,000 amp. Revising the model to make it more realistic, he assumes that a 20 km. horizontal line current 6 km. above the earth joins a 6 km. vertical line current to the earth together with an equal earth image. The current necessary to produce the observed 15 Gamma field is then only 225 amp.

Consideration of the electromagnetic effects produced by tornadoes suggests that some UFO sightings may have been stimulated by these storms, and that continued photographic, geomagnetic and radar observations would be useful in studying them.

The claim that UFOs produce powerful magnetic fields could also be investigated by proton magnetometer measurements. The problem, however, is a familiar one: thus far it has not been possible to bring instrumentation to the scene of a sighting while UFO phenomena were still observable.

Papers by Vonnegut and Weyer (1966) and Colgate (1967) contain extensive lists of references on tornado energy phenomena. Much of the information for this section was supplied by Dr. Joseph H. Rush, High Altitude Observatory, National Center for Atmospheric Research, Boulder, Colo.

BACK TO TOP

12. Lasers

The use of lasers in tracking objects is analogous to the use of radar, the principal difference lying simply in the wavelength of the radiation in the emitted pulse. As in radar tracking, the information obtained is range, azimuth, and altitude, but the accuracy of laser

[[1256]]


ranging is expected to be better than in 3 cm. radar by a factor of two, because of the smaller effect of atmospheric water vapor on the refractive index at the laser wavelength.

The extremely good collimation of a laser beam, where the angular spread is less than 2 x 10-5 radians (a few seconds of arc), is a two-edged sword insofar as the development of laser ranging is concerned. The narrow beam increases the accuracy of azimuthal data and diminishes the transmitted power required to yield a detectable return signal; but this very narrowness increases the difficulty of scoring a hit on a rapidly moving object in low orbit.

Laser ranging has been in the developmental stage for only a few years and, at the present state of the art would be of only limited value in UFO investigations. However, laser technology is advancing rapidly and it seems quite probable that future laser ranging devices could be useful in UFO searches.

BACK TO TOP

13. Observations and Comments

The description of a phenomenon requires the collection of many of its qualitative and quantitative aspects. If the data relating to these aspects is sufficient to permit the construction of a model then this model can be identified as belonging to one or another known category of phenomena if their mutual similarities are numerous enough. Conversely, if the similarities are not numerous enough, it may be necessary to identify the model as a member of a completely new category.

In the majority of UFO sightings, the amount, type and quality of the data have been insufficient even to describe the event, to say nothing of identifying it with a known classification. Data from many other sightings have been adequate for identification with familiar phenomena. to a reasonable level of confidence, but in no case have the data been either detailed or accurate enough to class the event as a new phenomenon.

The lack of instrumented observations has curtailed investigation of a number of events which sounded fascinating and on the threshold

[[1257]]


of revealing something novel. No matter how detailed or how intelligent the reports of observers, qualitative statements could not serve to define an unfamiliar phenomenon. To do so requires a quantitative description of a number of basic characteristics, some of which are listed below:

  1. Dimensions.

  2. Position, that is, coordinates in some frame of reference, usually with respect to the observer.

  3. Shape.

  4. Mass.

  5. Motion - velocity and accelerations, particularly with reference to the method of propulsion.

  6. Interactions with other systems - effects of electric and magnetic fields on surrounding objects, emission of energy in the form of exhausts, light and sound, aerodynamic lift, ionization.

  7. Matter primarily involved - the composition and state of matter and its temperature, rigidity and structure.

  8. Origin - the genesis of the phenomenon, the conditions which gave rise to it, its presence in and mode of transport to the region in which it was observed.

Instrumentation to acquire knowledge of these characteristics must be designed with appropriate regard for the behavior shown both by UFOs and some other phenomena which can be loosely classed together as objects difficult to identify. Any instrumentation for the detection and identification of these objects must be elastic enough to cover the wide range of expected behavior. A comparison of various salient characteristics of some objects observed in the atmosphere is set out in Table 6.

[[1258]]


Table 6

Characteristics of Some Objects Observed in the Atmosphere


  Meteors Satellites and Satellite re-entries Aircraft Tornadoes UFOs

Point source (P.S.) or extended object (E.O.) P.S. unless fireball P.S. unless re-entry P.S. by night E.O. by day E.O. P.S. by night E.O. by day

Self-luminous yes reflected light yes (re-entries) yes, navigation lights yes?* yes, at night

Luminance high low low low low to high

Direction of motion-unpredictable, linear, ballistic or orbital linear or ballistic linear or orbital straight or slowly curving slowly varying unpredictable

Electromagnetic effects, other than visual some evidence exists** none none possible but not estab1ished** sometimes

Close approach to or contact with ground infrequently re-entry only yes yes so reported

Distance to observer many miles many miles from close to far usually several miles from close to many miles

*(Vonnegut and Weyer 1966)
**(Romig, 1963)
***(Vonnegut, 1968)

[[1259]]


Table 6 (cont'd)

Characteristics of Some Objects Observed in the Atmosphere


  Meteors Satellites and Satellite re-entries Aircraft Tornadoes UFOs

Duration of appearance 1-15 sec. <5 min. <5 min. a few sec. to many min. a few sec. to many min.

Velocity range <17 km/sec <8 km/sec <0.6 km/sec <0.03 km/sec unpredictable

Altitude 10-100 km. 100-2,200 km. <26 km. >13 km. and <19 km. zero to very high

Direction isotropic Constant; W to E, polar or E to W isotropic isotropic isotropic

Other     characteristic illumination most common in central states no apparent geographical distribution

[[1260]]


An explanation of some of the statements in the table is of interest:

Duration:

  1. The large majority of meteors have been observed to have a duration shorter than 15 sec. Thus if a meteor moving at 30 km/sec at an altitude of 80 km. is visible over 160° of sky, its path length will be

    d = 2 x  80 km.
    tan 10°
     = 900 km.

    so that it will have a maximum distance from the observer of 450 km. Therefore, it will be visible for not more than

    t =  900
    30
    = 30 sec.

    However, most meteors do not usually have the luminance to be seen at a distance of 450 km.

  2. In the case of satellites, one which has a 90 min. period at an altitude of 200 km., and can be seen over 160° of sky, will be visible for about 4.5 min.

  3. Tornadoes occasionally persist for a long time and travel many miles.

Velocity range:

  1. The lowest meteor velocity (prior to the last few seconds before impact) is 17 km/sec. The greatest velocity imparted artificially to a small object is 14 km/sec by means of a four-stage rocket in a ballistic trajectory and a final boost with a shaped charge. (McCrosky, 1968)

  2. Satellites with a near-escape velocity of 17,000 mph have a velocity of only 7.6 km/sec.

  3. For aircraft, 2,000 km/hr or 0.6 km/sec.

  4. A tornado usually moves at 5-70 mph., (0.002-0.03 km/sec).

Altitude:

  1. The Prairie Network attempts to get stereo-pairs of meteor photographs for trajectories at 40-80 km. in altitude and downstream single photos at 10-40 km. altitude to predict the point of impact.

[[1261]]


  1. Perigee and apogee of most satellites lie in the range of 100-2,000 km.

  2. Aircraft: 26 km. = ~16 mi. = ~80,000 ft.

    Vonnegut (1968) states that although thunderstorms spawn tornadoes, the higher the storm the greater the probability of formation. "Ordinary" thunderstorms at an altitude of about 8 mi. rarely produce tornadoes while those at 12 mi. often do."

Azimuth:

  1. Meteors appear in a region bounded by a few degrees on each side of the plane of the ecliptic and their trajectories will be oriented isotropically with respect to their points of origin.

  2. Satellites launched from Cape Kennedy will travel from west to east, with a small southward component; those launched from Vandenberg AFB are most often in a polar orbit, though some are in retrograde orbit.

  3. Aircraft, of course, will be seen moving in any direction.

  4. Tornadoes seem to have no observable directional pattern.

Review and Discussion of Several Instrumental Methods

  1. The Prairie Network covers about 80% of the volume of space above each camera station. This is as good a coverage as can be found with any instrument except certain types of radar, all-sky cameras, and airglow photometers.

  2. The coverage is continuous, during periods of good visibility from dusk to dawn, or, roughly, about 30% out of every day. Radar has the advantage of daytime coverage over optical systems, but resolution and identification is not as good. The presence of "angels" and other anomalies, complicates the interpretations.

  3. Certain other means of detection, such as photometric scans, have much longer ranges and therefore probe very much larger volumes of sky. But these systems suffer from the same disadvantages as radar.

  4. No other optical network exists which is as extensive as the Prairie Network, the coverage of which is ~0.13 of the sky over the U.S.

[[1262]]


  1. The network .has been designed to produce data which allows the direct computation of altitude, azimuth, velocity, and brightness from which loss of momentum and impact coordinates can be found. Radar will acquire the same data but will record neither the visual identifying signals emitted by a plane nor the brightness of a meteor.

  2. Objects recorded by a photographic time exposure show a continuous projection of their position in time. In many radars the object is located only once every sweep and since each sweep may have a period of six to 15 sec., rapid course changes may result in an inability to identify successive images as belonging to the same object.

  3. Although the network is at present purely pictorial, it may shortly be improved by the addition of a spectrometric camera at each station.

  4. Devices such as airglow photometers cover the sky well but also have shortcomings similar to radar because each scan at a given zenith angle requires a relatively long time and a complete sky survey requires several scans taking several minutes.

  5. Most photometric scanners plot intensities as a function of time on paper tape. Reduction of this data to coordinates is not as accurate as interpretation of the network film, although it is good enough for airglow and aurora studies.

  6. Differentiation between near-orbital or ballistic objects and the star background is much simpler in network photographs than on photometric scan tapes because star trajectories on film are obvious, whereas on tapes a pulse produced by a reflecting or self-luminous object can be distinguished from a pulse produced by a star only by comparing its coordinates with those given for stars.

  7. Scanning radar sky coverage is very good, but identification of objects photographed on the radar scopes is much more difficult than objects seen photographically, both because of poor resolution and because of the lack of characteristic patterns such as flashing lights on planes, and so forth. Weather radar, however, would be a useful adjunct to a photographic patrol, particularly

[[1263]]


since a portion of the weather radar system is interlaced with the network. In general, it can be said that the most effective use of radar lies in confirmation of velocity, range and direction.

  1. Image Orthicons and Vidicons: The use of these photoelectric devices is growing, largely because their sensitivity is greater than film by a factor up to 10^4. Such systems can also store and reproduce the image immediately. These attributes make them valuable instruments in investigations of aerial phenomena of any kind, including UFOs.

  2. A number of UFO reports have indicated electromagnetic interactions with terrestrial systems: radio and TV interference, stalled internal combustion engines, and the like. It would be desirable to investigate the frequency with which UFOs exhibit such interactions as well as the field strengths and direction. No network of stations making routine recordings of atmospheric electric potential exists at present in the U.S. Electric potential measuring devices might be incorporated into joint geomagnetic weather radar and Prairie Net work system at a later time.

  3. There have been persistent reports that sometimes sounds accompany the passage of large meteors (fireballs) and the re-entry of satellite debris. There is evidence that these sounds have been heard at great distances, sometimes simultaneously with the time of passage. This suggests that fireballs give rise to electromagnetic fields which either interact with the surroundings of the observer, or directly with the observer himself, to produce audible waves (Romig, 1963, 1964). Stations containing geomagnetic or electric potential measuring devices should also be equipped with tape recorders and appropriate acoustical sensing devices.

  4. Other instruments such as ultra-violet and infra-red sensors, and radiation-counters would also be desirable.

Existing Instrument Systems of Limited Value

  1. The Super-Schmidt cameras developed for meteor studies are sensitive and have a 55° field but they are few in number.

[[1264]]


and individually cover only a hundredth of the area of sky covered by one Prairie Network station. The Baker-Nunn cameras which were designed for satellite tracking have a much smaller field and although there are perhaps 16 of them in all, they are scattered all over the world.

  1. Sky surveys made through large astronomical telescopes cover too little sky at each exposure. Because of their slow photographic speed, only very bright objects moving with respect to the star background will be recorded.

  2. The Tombaugh Survey for small natural earth satellites was an extremely systematic search (Tombaugh, 1959). This technique would hardly be suitable for photographing UFOs.

The capabilities of existing instrumental systems to record the characteristics necessary for quantitative descriptions of UFOs vary widely. The Prairie Network can supply data on position and motion at all times; under ideal conditions it might be capable of determining dimensions and shape but it cannot directly describe mass, interactions, the matter associated with the event, its origin or manner of locomotion.

Radar is more limited in its information return. It can report position and motion, even when the phenomenon is invisible to the network, but it cannot furnish information on any other characteristic, with the possible exception of the state of matter. Photometric scanners are even more limited.

Determining mass and kind of matter, and extensive analysis of the structure and organization of an UFO require that such an object, if one exists, be made continuously available for instrumented study.

If all the eight characteristics listed at the beginning of this section describe adequately an UFO, then no network, simple or complex as presently constituted, can help us far along the road toward the identification of that type of event which today defies explanation.

What is required is a modified and extended network, so designed that its component systems complement each other, and so integrated

[[1265]]


that it can provide storable data in a form suitable for interdisciplinary study.

More specifically, the network should be organized along the following lines:

  1. In the interests of economy and speed, arrangements should be made to have access to the output of the Prairie Network, and the cooperation of its investigators.

  2. Similar arrangements should be made with the Weather Radar Network and a program of photography developed along lines suitable for the acquisition of data on tornadoes and other transient phenomena not detectable by time-exposure photographs.

  3. Simultaneous observations with the several geomagnetic observatories which lie in or near the combined Prairie Network-Weather Radar nets should be provided for.

  4. Link these three networks, and other devices, such as tape recorders and radiation monitors, together to a single time base. This step is important, for example, in testing reports that fireballs have been heard at the same time as their appearance, although their distance from the observer would normally require a many-second interval between sight and sound.

  5. The tedium of a patrol can be relieved by the installation of various automatic sensors, but the degree of discrimination offered by these devices is often not as great as that of the human eye. It is true that the eye is, in general, incapable of making quantitative and reliable observations suitable for network studies, but it is a very sensitive detector with a wide angle of view and search, and these qualities should be used. It will be recalled that Tombaugh supplemented instrumental with visual search for small natural satellites. Visual search could probably benefit from a tie to an "early warning" communications network of amateur radio operators.

  6. Photoelectric and electromagnetic sensors cannot only give early warning of the approach of an event of interest, but also are capable of actuating detecting and recording instruments much more rapidly than the human on patrol.

[[1266]]


  1. The operation of the network can be made flexible. Costs can be reduced by maintaining a minimum staff in maximum collaboration with other search organizations.

  2. Combined network operations should start as soon as the photographic, radar and geomagnetic nets are linked in time. Installation of additional instrumentation should be deferred until a backlog of observations has been studied.

The cost of a program organized in this way should be two to three orders of magnitude less than most current proposals. The capital and operating expenses of the Smithsonian Meteorite Recovery Project can be taken as a measure of these costs. It is estimated that to duplicate the Prairie Network would cost about $150,000, not including the cost of the cameras and lenses which were lent by the U.S. Air Force. It is difficult to arrive at that part of the total operating expense for meteorite research applicable to an UFO network because the cost figures include operation and data reduction of Super-Schmidt cameras at Wallops Island, and the new image orthicon installation at Urbana in conjunction with the radar at Havana, Ill. The total annual expense, however, can serve as a guide for the proposed combined network:


Running and maintenance, Lincoln, Neb. $25,000
Supplies: film, chemicals for 64 cameras ($500/camera/year) 32,000
Scanning of film 10,000
Data reduction, all projects 65,000
Astronomers' salaries etc. 28,000

$160,000

Assuming that the combined network will not have to bear any of these costs, it would seem that, initially, at least, its expenses could be limited to the salaries of a principal investigator, a junior investigator and one technician, the cost of film exposed by the Weather Radar scope cameras, travelling expenses and miscellaneous items. It

[[1267]]


would be surprising if expenses would exceed $50,000 annually. Because of the rarity of the UFO phenomena, the investigation should continue for a minimum of five years. It is anticipated that the total cost would exceed $250,000, however, because preliminary results would suggest equipment modifications and additions.

BACK TO TOP

14. Recommendations

The problems involved in sightings of UFOs warrant the mounting of an instrumented effort to arrive at reasonable identifications of the several phenomena involved, and to add to the limited knowledge which exists about those phenomena. Present knowledge amounts to little more than suppositions.

Popular preoccupation with the notion that UFOs may be intelligently guided extraterrestrial space ships has had one undesirable effect: it has embedded in the term "UFO" the unfortunate connotation that if a phenomenon is unidentified it must somehow be extra-terrestrial.

It has become apparent that the clarification of the "unidentifiable 1%" referred to by Hynek (1966) may more likely result from investigating several rare phenomena, rather than one. If evidence of extraterrestrial intelligence is uncovered by the study, then the goal of the research can be changed and a full-scale investigation launched.

Until that time comes - if it does - the pursuit of knowledge about the less dramatic phenomena can go on in a modest way, using already established facilities, extended when, as and if the need arises, with additional equipment.

With the de-emphasizing of the ETI hypothesis must also come a complete elimination of the term "UFO." Its connection with an otherwise soundly-based research program can serve only to impair that program's effectiveness. After all, it is beginning to look like a misnomer in certain cases: the sighting may not involve an "object," meaning a solid mass; it may not "fly" in the sense of having aerodynamic lift, and often it remains "unidentified" only briefly.

[[1268]]


Several suggestions have been made on investigating what will now be called "strange phenomena." Dr. James E. McDonald, of the University of Arizona has recommended a program of several steps, the cost of which would range from "a few tens of millions of dollars" to "global expenditures at the level of billions of U.S. dollars per year." (McDonald, 1967, 1968).

W. T. Powers of the Dearborn Observatory has discussed the design of a new photographic network covering 1% of the area of the United States; the cost for this coverage would amount to about $2x106 and $2x10,7 for a 10% coverage of the U. S. (Powers, 1968). Dr. G. H. Rothberg in his report to this project of an attempt at first-hand observations and UFO photography recommends new camera design and a "small" effort costing perhaps $1x107 (see Case 27). Larry W. Bryant, after suggesting an Earth-surveillance satellite especially designed for the purpose of monitoring UFO activities, finds that it might cost $5x107 and require five years' effort from funding and design until launch (Bryant, 1967).

The UFO phenomenon is extremely rare. Whereas some 500 meteors per year have trajectories which can be reconstructed from photographs, and none has been recovered in the three or four years of the Prairie Network's existence, Hynek states that only 600 UFO sightings since 1947 have remained unidentified by the Air Force (Hynek, 1966). If this number is adopted as the equivalent of the "1% unidentifiable" events, sightings due to strange phenomena occur at the rate of only 30 per year. Other arguments further lower this figure to 18 or less per year (Page, 1968).

The number of sightings of rare phenomena is so low that it is impossible to make a meaningful geographical distribution. Whether the site of the Prairie - Weather Radar - Geomagnetic Network will eventually turn out to be the best location cannot now be predicted; its present advantage lies in the fact that the three detecting systems are interlaced over a small area, thus facilitating an investigation involving several disciplines.

[[1269]]


It is because these sightings are so infrequent that the recommendation is made to use existing facilities, wherever they happen to be, and to proceed with such studies in a measured and thoughtful manner.




[[1270]]


BACK TO TOP
